High quality PlumbRight lever ball valve with a red handle to indicate hot water supply, Compression ends manufactured to BS EN 1252-3 and CE approved. Lever ball valves enables an easy adjustment of the water flow where being parallel to the pipe will allows a full flow through the valve, adjusting to be perpendicular to the pipe will block the flow of water. Moving the lever between 0 and 90 degrees controls the flow. (Avalible in red, blue & yellow). Contact us for more details of lever ball valve !!!
| Product Description |
Lever ball valve
High quality PlumbRight lever ball valve with a red handle to indicate hot water supply, Compression ends manufactured to BS EN 1252-3 and CE approved. Lever ball valves enables an easy adjustment of the water flow where being parallel to the pipe will allows a full flow through the valve, adjusting to be perpendicular to the pipe will block the flow of water. Moving the lever between 0 and 90 degrees controls the flow.
Download catalogue: Lever ball valve
Attributes of lever valve |
※ CE Approved
※ Manufactured to BS EN 1252-4
※ Maximum operating pressure: 25 bar
※ Temperature range:from -20℃ to +95℃
※ Body Material: 58-2 Brass
※ Handle material: Steel
※ Suitable for fluids and air
※ Full bore flow for efficiency and reduced wear and tear
※ Size: 15mm, 22mm, 28mm, 35mm, 42mm, 54mm
| Specification of lever valve |
Specification | ||
1 | colour | Red, blue |
2 | Connection type | Compression fittings |
3 | Manufacturer Guarantee | 5 years |
4 | Pack size | 1 |
5 | Parent colour | Red, Blue |
6 | Pieces in pack/bag | 1 |
7 | Pipe fitting requirements | Can be fitted by any competent person when used with water system |
8 | Product diameter | 15mm, 22mm, 28mm, 35mm, 42mm, 54mm |
9 | Product type | Lever ball valve |
