ASB PP-R PIPE fittings are made of Polypropylene Random, which has comprehensive physical and chemical property, as well as Hygiene property. With the high-quality materials. ASB PP-R pipe fittings meet the DIN8077/8078 standard .Depending on the pressure, the pipes can be used in temperature up to 70°C with an extrapolated service life up to 50 years.
| ASB PPR pipe fittings characteristics: |
1)100% excellent raw materials, safe and hygiene.
2)Drinking water pipeline system.
3)Recyclable ,benefit to the environment
4) Resistance to abra...
| Basic information: |
MOQ: 5 carton boxes/ item
Delivery Port: Ningbo or Shanghai
Payment Term: TT or LC
Standard: DIN8077 DIN8078, ISO15874
Material: Imported Raw Material from Korea, SINOPEC from China and Taiwan HYOSUNG
Brand Name: ASB or OEM
Color: White, Green, Grey or produce as request
Sample: Free Sample Available
ASB PP-R fittings are made of Polypropylene Random, which has comprehensive physical and chemical property, as well as Hygiene property.
With the high-quality materials. ASB PP-R pipe fittings meet the DIN8077/8078 standard. Depending on the pressure, the pipes can be used in temperature up to 70°C with an extrapolated service life up to 50 years.
1)100% excellent raw materials, safe and hygiene.
2) Drinking water pipeline system.
3) Recyclable ,benefit to the environment
4) Resistance to abrasion and corrosion.
5) Connected by welding ,leakage prohibit
6) Long life span, Minimum 50 year’s life time at 60 or 70°C and 10 bar maximum pressure.
| Technical requirements: |
Characteristic | Requirements | Test Methods | |
Physical characteristics for PPR pipe | |||
Impact resistance of PPR pipe (0℃) | ＜10% | ISO 9854 | |
Longitudinal reversion of PPR pipe (135℃) | ≤2% | EN 743 | |
Thermal stability by hydrostatic pressure testing of PPR pipe (110℃, 1.9Mpa) | No bursting during the test period | EN921
| |
Melt Flow Rate of PPR pipe (2.16Kg,230℃,10min.) | 30 % maximum difference compared with compound | ISO 1133 | |
Mechanical characteristics for PPR pipe | |||
Resistance to internal pressure | Hydrostatic (hoop) stress 16.0Mpa; Temperature 20℃; Test time 1 hour No failure during the test period | EN 921
| |
Hydrostatic (hoop) stress 5.1Mpa; Temperature 95℃; Test time 22 hour No failure during the test period | |||
Hydrostatic (hoop) stress 4.2Mpa; Temperature 95℃; Test time 165 hour No failure during the test period | |||
Hydrostatic (hoop) stress 3.5Mpa; Temperature 95℃; Test time 1000 hour No failure during the test period | |||
| FAQ |
Q: What the raw material?
A: AIRIPRO, SINOPEC and HYOSUNG, pure and new raw material, no recycle
Q: What is your MOQ?
A: Depend on different size. Please check with the sales.
Q: What is the production ability? Or the delivery time?
A: Normally 15-20days for one 40HQ container
Q: What is the regular shipping port?
A: Ningbo or Shanghai
Q: What is your payment ?
A: 30% down payment, balance against BL Copy or Irrevocable L/C
Q: Can we have sample ?
A: Free Sample
