Plastic PPR Ball Valve

Plastic PPR Ball Valve
Product Introduction:
ASB PPR Ball Valves is mainly made of plastic part and brass part. Specially our PP-R material is a high molecular weight hydrocarbon, insoluble in water, biologically inert, does not produce harmful substances in the production and processing process, the use of high temperature will not make the water produce bad organ sensation, by the health department testing meets the national food hygiene standards. The PP-R material can be recycled, so it is a green building material that can be used in pure drinking water piping systems.
Send Inquiry
Chat Now
Description
Technical Parameters

Asb PPR Wholesale Plastic PPR Ball Valve Red Handle Normal Brass Core 20-63mm Size Pn25 PPR Fitting Valve for Pipe


Product Description

Water ball valve

ASB PPR Ball Valves is mainly made of plastic part and brass part. Specially our PP-R material is a high molecular weight hydrocarbon, insoluble in water, biologically inert, does not produce harmful substances in the production and processing process, the use of high temperature will not make the water produce bad organ sensation, by the health department testing meets the national food hygiene standards. The PP-R material can be recycled, so it is a green building material that can be used in pure drinking water piping systems.

145





Product Structure


Part NumberPart NameMaterials
1BodySINOPEC PPR
2SEAT WASHERPTFE
3STEM O-RINGEPDM
4BallHPb 58-2 Brass
5STEMHPb 58-2 Brass
6HANDLESINOPEC PPR
7CAPPP


Products attribute

Name

Water ball valve

Body material

Hpb-58-2 brass

Stem material

Brass

Ball material

Brass

Seat material

PTFE

Body seal material

PTFE

Nominal pressure

2.5Mpa(400psi)

Working medium

Water, oil, gas

Working temperature

T<120℃

Pressure test conform to

ISO520

Parallel pipe thread conform to

ISO228

Size

1/2”-2”

Handle type

Lever or Butterfly

Standard

EN13828 CE ACS(1101)



Product Features and Advantages

1. Light Weight
the wright is 1/9 of steel pipes
1/10 of copper pipes
it can be installed by the staff very easily
2. Good heat resistance and low thermal conductivity
Instantaneous use temperature can reach 95ºC.
Long-term use temperature up to 75°C
Good insulation performance
3. Good corrosion resistance
No chemical effects on all ions in the water or chemicals in the building
No rust
No corrosion.
4. Strong tubing connection
Good hot melt properties
Can connect pipes, fittings, ball valves of the same material into a single unit
Eliminate the potential for water leakage
